TSGC-2 2KVA Variac Voltage Regulator Three Phase Voltage Regulator Input 380v Output 0-430v

China TSGC-2 2KVA Variac Voltage Regulator Three Phase Voltage Regulator Input 380v Output 0-430v supplier

Large Image :  TSGC-2 2KVA Variac Voltage Regulator Three Phase Voltage Regulator Input 380v Output 0-430v

Product Details:

Place of Origin: Zhejiang , China ( Mainland )
Brand Name: YOMIN
Certification: CE / RoHS
Model Number: TSGC2-1.5

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Price: Negotiation
Packaging Details: Export carton , 1 Piece / Carton/Wooden Cases
Delivery Time: 3-5 days working days after received your payment
Supply Ability: 2000 Pieces Per Week
Contact Now
Detailed Product Description
Rating Power: 1000VA Color: White
Current Type: AC Coil Number: Manual
OEM: Accept Modle: TSGC2-1.5
Package Details: Wooden Cases Or Export Carton Phase: 3Phase
Insulation Resistance: >2M Manual Control: A Control Button
Is_customized: Yes Usage: SVC
Power: 1.5kva Output Current: > 2MΩ

Three Phase Voltage Regulator Input 380v Variac Adjustable/ TSGC-2 2KVA output 0-430v Variable Transformer

Description

TSGC2-1.5 series voltage regulator has artistic appearance .undistorted waveform,small volume.light weight ,high efficiency ,easy to operate ,reliable movement and soon characteristics,the peromance is more superior ,it can be widely used in the industry(for example chemical ,metallurgy.

YOMIN   TSGC2-1.5 TSGC2-3 TSGC2-6 TSGC2-9 TSGC2-10 TSGC2-15 TSGC2-20 TSGC2-30 TSGC2-40 TSGC2-60series Contact Voltage Regulator,TSGC 3phase 380V Power  1.5kVA-60KV   Input  380V  output  0-430V TSGC Voltage regulator

TSGC-2 2KVA Variac Voltage Regulator Three Phase Voltage Regulator Input 380v Output 0-430v


Technical parameters



      Item    Capacity    Input Voltage   output Voltage output Current   Case
    Model       (kva)         (V)           (V)         (A)     (Pcs)
TSGC2-1.5       1.5     380 0-430v  2 2
TSGC2-3        3     380 0-430v  4 1
TSGC2-6        6      380 0-430v  8 1
TSGC2-9        9     380 0-430v  12 1
TSGC2-10       10     380 0-430v  12 1
TSGC2-15       15     380 0-430v  20 1
TSGC2-20       20     380 0-430v  27 1
TSGC2-30       30     380 0-430v  40 1
TSGC2-40       40      380  0-430v  53 1
TSGC2-60       60     380 0-430v  80 1



Scope of Application
It is widely used in industry (as chemical industry, metallurgy, instruments, meters, electromechanical manufacturing, light industry etc.), scientific experiment, public facilities and domestic electric appliance to fulfill voltage regulating, temperature control, speed regulating, light adjusting, power control and so on, it is an ideal AC regulated power source.

The products is special auto transformer which is connected in different forms.Its output voltage can be regulated smoothly and continuously from zero to the maximum value.The provision of indication is made for the models TSGC.
