TSGC2 - 30 Three Phase Voltage Regulator

Name: TSGC2 - 30 Three Phase Voltage Regulator
Brand: YOMIN
SKU: TSGC2 - 30
Rating: 4.6 (167 reviews)

TSGC2 - 30 Three Phase Voltage Regulator supplier

Large Image : TSGC2 - 30 Three Phase Voltage Regulator

Product Details:

Place of Origin:	Zhejiang , China ( Mainland )
Brand Name:	YOMIN
Certification:	CE / RoHS
Model Number:	TSGC2 - 30

Payment & Shipping Terms:

Minimum Order Quantity:	1 Piece
Price:	Negotiation
Packaging Details:	Wooden packing , 1 Piece / Carton
Delivery Time:	5 - 20 working days after received your payment
Payment Terms:	L/C , T/T , Western Union , Paypal
Supply Ability:	1000 Pieces Per Week

Contact Now

Detailed Product Description

Voltage Setting:	Manual Control	Standards:	VDE0550 , IEC204-1 , IEC61588 , EC439
Quality Assurance:	18Months	Item Condition:	Brand - New
Dimension:	34 * 42 * 58	Color:	White
High Light:	automatic voltage regulator , variable voltage output transformers

TSGC2 - 30 Three Phase Voltage Regulator , Variac For Generator 40A Output 30000VA Regulator /

Description :

TDGC2 TSGC2 TDGC2J TSGC2J Voltage Regulator is designed and developed with the international advanced compens-ation technology. It can keep the output voltage steady automatically when the network voltage fluctuated or the load current varied, which can ensure the consumer runs moothly. It has the advantage of large capacity, high efficiency, no wave form distortion, simple operation and maintenance, reliable running, full-capacity output under tower input voltage if compared with other voltage stabilizer. the product is provided with over-voltage, over-current, phase sequence and so on protection function.

Usage :
TDGC2 TSGC2 TDGC2J TSGC2J Voltage Regulator is suitable for electric supply in small-sized plant, workshop and department in middle, large size mining enterprise, it can be widely used in the precision machine tool, precision instrument, test device, elevator, imported electromechanical device, production flow lime in the mining enterprise, oil field, railw-ay, building site, school, hospital, hotel, scientific research department and so on, it is also suitable for the user in the LV electric network and with low power voltage and big wave range.

Technical parameters :

Capacity.....................................................30,000VA
Output Current..........................................40A
Output........................................................0~430VAC
Frequency.................................................50/60Hz
Input...........................................................380VAC
Insulation Resistance................................>2MΩ
No. of Phase.............................................Three-Phase
Winding Material.......................................100% Copper
Max.Temperature.......................................60℃
Insulation Class.........................................Class B (130℃)
IP/NEMA Rating.........................................IP20
Variable Operation.....................................Manually Operated Rotary Knob
Portable Carrying Grip...............................Provided
Pollution Rating.........................................Class III
Analog Voltmeter Display...........................Provided
Housing Material.......................................Shock-Proof Metal
Voltage Setting..........................................Manual Control
Standards..................................................VDE0550,IEC204-1,IEC61588,EC439
Sample Service.........................................Pay to Provide
Quality Assurance....................................18Months
Item Condition...........................................Brand-New

Item	Capacity	Input Voltage	Output Voltage	Output Current	Case Qty.
Model	(kVA)	(V)	(V)	(A)	(Pcs.)
TSGC2-1.5	1.5	380	0~430	2	2
TSGC2-3	3	380	0~430	4	1
TSGC2-6	6	380	0~430	8	1
TSGC2-9	9	380	0~430	12	1
TSGC2-10	10	380	0~430	12	1
TSGC2-15	15	380	0~430	20	1
TSGC2-20	20	380	0~430	27	1
TSGC2-30	30	380	0~430	40	1
TSGC2-40	40	380	0~430	53	1
TSGC2-60	60	380	0~430	80	1
