High Efficiency AC 220V / 0 - 260V / 200VA 0.8A Variac Transformer Autotransformer

Certification
Good quality Ceramic Tile Spacers for sales
Good quality Ceramic Tile Spacers for sales
we received the goods with nice packing and reliable quality, please ship the new order next month earlier. thanks.

—— Mr. ABD HALIM

STS prepaid meter test by our engineer, operation smoothly according to your English Use Manual, Nince cooperation

—— Mr. Rodrigo Araujo

new mould case din rail meter single phase 5(60)A and 3x10(100)A delivered to our authority, they are very satisfied with the new items. will inform the new orders,thanks

—— Mr. Sathyanarayana D

I'm Online Chat Now

High Efficiency AC 220V / 0 - 260V / 200VA 0.8A Variac Transformer Autotransformer

China High Efficiency AC 220V / 0 - 260V / 200VA 0.8A Variac Transformer Autotransformer supplier
High Efficiency AC 220V / 0 - 260V / 200VA 0.8A Variac Transformer Autotransformer supplier High Efficiency AC 220V / 0 - 260V / 200VA 0.8A Variac Transformer Autotransformer supplier

Large Image :  High Efficiency AC 220V / 0 - 260V / 200VA 0.8A Variac Transformer Autotransformer

Product Details:

Place of Origin: Zhejiang, China (Mainland)
Brand Name: YOMIN ELECTRIC
Certification: CE/RoHS
Model Number: TDGC2-0.2

Payment & Shipping Terms:

Minimum Order Quantity: 1 Piece
Price: Negotiation
Packaging Details: Export carton , 4 Pieces / Carton
Delivery Time: 5 - 10 working days after received your payment
Payment Terms: L/C , T/T , Western Union , Paypal
Supply Ability: 2000 Pieces Per Week
Contact Now
Detailed Product Description
Input Volt: 220VAC Output Volt: 0~260VAC
Insulation Resistance: >5MΩ Efficiency: >90%
Capacity: 0.2KVA Current Type: AC
Color: Red

AC 220V / 0 - 260V / 200VA 0.8A variac transformer autotransformer with reasonable price



Product Description :


Bench top 0.8A Variac transformer with high efficiency and no waveform distortion. Rated at 220V input with an output voltage of 0-250V. Maximum output current is 0.8A. This auto transformer is VERY popular for home coffee roasting machines. It allows much greater control of the temperature of the roasting of coffee beans. They can also be used in science labs, audiophile (Great for old Tube Amplifiers), Science lab, hobby, film & video lighting applications. The auto transformer or Variac (both terms apply to the same item) is used to adjust the AC power either up or down. For instance if the AC power from the power company was 125 VAC and your application required 90 VAC, then this Auto transformer could be plugged in and the AC voltage could be adjusted to the desired level. It does not convert AC to DC. It is AC in and AC out. Also, the unit will not affect the cycle rate from the power company. If your power system is providing 60Hz, the Variac-auto transformer will not change that. This unit is rated up to 0.8 Amps or 0.2KVA.

Note: Variacs are not compatible with most GFI (Ground Fault Interrupter) wall outlets. We have found that the inductive load that the Variac represents is not compatible with most GFI circuits and they will trip the breaker.





Technical parameters :
  • Capacity.....................................................0.2KVA
  • Output Current...........................................0.8A
  • Output.........................................................0~250V AC
  • Frequency..................................................50/60Hz
  • Input............................................................220V AC
  • Insulation Resistance..................................>5MΩ
  • No. of Phase...............................................Single-Phase
  • Winding Material........................................100% Copper
  • Max.Temperature.......................................60℃
  • Insulation Class..........................................Class B (130℃)
  • IP/NEMA Rating..........................................IP20
  • Variable Operation....................................Manually Operated Rotary Knob
  • Portable Carrying Grip...............................Provided
  • Pollution Rating.........................................Class III
  • Analog Voltmeter Display...........................Provided
  • Housing Material.......................................Shock-Proof Metal
  • Voltage Setting.........................................Manual Control
  • Standards.................................................VDE0550,IEC204-1,IEC61588,EC439
  • Sample Service.........................................Pay to Provide
  • Quality Assurance....................................18Months
  • Item Condition...........................................Brand-New
Item Capacity

InputVoltage

OutputVoltage

OutputCurrent

CaseQty.

Model (kVA) (V) (V) (A) (Pcs.)
TDGC2-0.2 0.2 220 0~250 0.8 12
TDGC2-0.5 0.5 220 0~250 2 6
TDGC2-1 1 220 0~250 4 4
TDGC2-2 2 220 0~250 8 4
TDGC2-3 3 220 0~250 12 2
TDGC2-5 5 220 0~250 20 1
TDGC2-7.5 7.5 220 0~250 30 1
TDGC2-10 10 220 0~250 40 1
TDGC2-15 15 220 0~250 60 1



Why Choose Us :

1. Experienced manufacturer more than 10 years.
2. Highly experienced production team in YOMIN factory work-shop.
3. QC Systerm: Quality controlled on all production lines, and QC inspectors work independently from the production line.
4. Good quality production with quick delivery.
5. Accepted OEM/ODM.
6. Accepted small MOQ.
7. Trade Assurance on Alibaba.
8. Factory certification: CE, RoHS and ISO9001 .
